2 Port VR Series Fuel Pressure Regulator

Description

2 Port VR Series Fuel Pressure Regulator
15-60 Psi – Fittings and Gauge Included
Overview
Holley EFI Billet Bypass Style Fuel Pressure Regulator Kits are part of a complete line of fuel system products from Holley. The included 12-848 regulator features a billet aluminum body and a black finish for corrosion resistance and good looks. The regulator contains 10 AN in/out ports, a 8 AN return port, a 1/8″ NPT gauge port, and a 1/8″ NPT vacuum port for Boost Reference (1:1). In addition, 3 adapter fittings, a barbed fitting for the vacuum port, a mounting bracket, and all necessary hardware are also included.
Features:

• EFI regulators are adjustable from 40-100 PSI base pressure
• Carbureted regulators are adjustable from 4 to 9 PSI base pressure
• Compatible with gasoline, methanol, and E85* (Compatible with
• 1/8??? NPT gauge port
• Designed for use with the Holley VR1 and VR2 Brushless in-line fuel pumps
• Can be referenced on a 1:1 ratio ???? includes a barb fitting and a -4 AN fitting for reference connection
• 2 port regulators feature a 10 AN O-ring inlet/outlet and return
• 4 port regulators feature a 10 AN O-ring inlet and return with (4) 8 AN O-ring outlets

Details:

• Color: Black Anodized
• Fuel System: EFI
• Fuel Type: Gasoline
• Material: Aluminum
• Pressure Range: 40-100 PSI
• Return Size: 10 AN O-Ring
• Style: EFI
• Warranty: Limited 90 Day
